MAIN APPLICATIONS
Low pressure lines, return lines, drain lines
CONTINUOUS SERVICE TEMPERATURE RANGE
-40°F / +250°F
-40°C / +121°C
RECOMMENDED FLUIDS
Mineral oils, vegetable and rape seed oils, glycol
and polyglycol based oils, synthetic ester based
oils, oils in aqueous emulsion, water
TUBE: Oil resistant synthetic rubber
REINFORCEMENT: One high resistance textile braid
COVER: Environment resistant synthetic rubber
APPLICABLE SPECS: SAE 100 R6 – EN 854 R6/1TE – ISO 4079-1 R6/1TE
TYPE APPROVALS: GOST-R
KEY PERFORMANCE
High flexibility Wide range of fluid compatibility MF2000® Multifit type couplability Push-On hose with MF2000® Push-Lock insert type without ferrule
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PART REF. | HOSE SIZE | R.O.D. | O.D. | MAX W.P. | BURST PRESSURE |
MIN. BEND RADIUS |
WEIGHT | MF3000 FITTING |
MF2000 FITTING |
||||||||
DN | dash | inch | mm | inch | mm | inch | bar | psi | bar | psi | mm | inch | g/m | lb/ft | |||
H09067005 | 5 | -3 | 3/16″ | – | – | 11.0 | 0.43 | 35 | 500 | 140 | 2030 | 35 | 1.38 | 93 | 6 | – | MF+M00820-03 |
H09067006 | 6 | -4 | 1/4″ | – | – | 12.6 | 0.50 | 30 | 430 | 120 | 1740 | 45 | 1.77 | 117 | 7 | – | MF+M00820-04 |
H09067008 | 8 | -5 | 5/16″ | – | – | 14.1 | 0.56 | 30 | 430 | 120 | 1740 | 65 | 2.56 | 135 | 10 | – | MF+M00820-05 |
H09067010 | 10 | -6 | 3/8″ | – | – | 15.8 | 0.62 | 30 | 430 | 120 | 1740 | 75 | 2.95 | 165 | 11 | – | MF+M00820-06 |
H09067012 | 12 | -8 | 1/2″ | – | – | 19.4 | 0.76 | 30 | 430 | 120 | 1740 | 90 | 3.54 | 215 | 15 | – | MF+M00820-08 |
H09067016 | 16 | -10 | 5/8″ | – | – | 23.0 | 0.91 | 30 | 430 | 120 | 1740 | 115 | 4.53 | 285 | 19 | – | MF+M00820-10 |
H09067019 | 19 | -12 | 3/4″ | – | – | 26.0 | 1.02 | 30 | 430 | 120 | 1740 | 140 | 5.51 | 325 | 22 | – | MF+M00820-12 |
H09067025 | 25 | -16 | 1″ | – | – | 32.0 | 1.26 | 30 | 430 | 120 | 1740 | 150 | 5.91 | 430 | 29 | – | MF+M00820-16 |
