MAIN APPLICATIONS
Medium-high pressure lines in extreme temperature conditions
(foundries, compressors, hydraulics within engine compartments, etc.)
CONTINUOUS SERVICE TEMPERATURE RANGE
-67°F / +275°F
-55°C / +135°C
MAX OPERATING TEMPERATURE
(Intermittent service) 300°F 150°C
RECOMMENDED FLUIDS
Mineral oils, glycols and polyglycols, transmission fluids, air with oil
vapours, mineral oils in aqueous emulsion (up to 212°F 100°C)
ATTENTION!
Compressed air applications require cover pin-pricking and additional safety devices
TUBE: Oil resistant synthetic rubber
REINFORCEMENT: Two high tensile steel braids
COVER: Blue synthetic rubber with high ozone, weather and heat resistance
APPLICABLE SPECS: Exceed EN 853 2SN SAE 100 R2AT – ISO 1436-1 2SN/R2AT
TYPE APPROVALS: ABS, BV, BV (MED), DNV, GL, GOST-R, LR, MSHA
KEY PERFORMANCE
Wide range temperature resistance • EN/DIN pressure rating • Outstanding ozone resistance •
Superior weather and UV resistance
|
|
|
|
|
|
|
|
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PART REF. | HOSE SIZE | R.O.D. | O.D. | MAX W.P. | BURST PRESSURE |
MIN. BEND RADIUS |
WEIGHT | MF3000 FITTING |
MF2000 FITTING |
||||||||
| DN | dash | inch | mm | inch | mm | inch | bar | psi | bar | psi | mm | inch | g/m | lb/ft | |||
| EQ2-04 | 6 | -4 | 1/4″ | – | – | 14.9 | 0.59 | 400 | 5800 | 1725 | 25010 | 100 | 3.94 | 390 | 26 | OPB | MF+M00910-04 |
| EQ2-05 | 8 | -5 | 5/16″ | – | – | 16.5 | 0.65 | 350 | 5070 | 1480 | 21460 | 114 | 4.49 | 435 | 29 | – | MF+M00910-05 |
| EQ2-06 | 10 | -6 | 3/8″ | – | – | 19.0 | 0.75 | 330 | 4780 | 1400 | 20300 | 127 | 5.00 | 535 | 36 | OPB | MF+M00910-06 |
| EQ2-08 | 12 | -8 | 1/2″ | – | – | 22.0 | 0.87 | 275 | 3980 | 1200 | 17400 | 178 | 7.01 | 645 | 43 | OPB | MF+M00910-08 |
| EQ2-10 | 16 | -10 | 5/8″ | – | – | 25.2 | 0.99 | 250 | 3620 | 1020 | 14790 | 200 | 7.87 | 770 | 52 | OPB | MF+M00910-10 |
| EQ2-12 | 19 | -12 | 3/4″ | – | – | 29.0 | 1.14 | 215 | 3110 | 900 | 13050 | 240 | 9.45 | 925 | 62 | OPB | MF+M00920-12 |
| EQ2-16 | 25 | -16 | 1″ | – | – | 37.0 | 1.46 | 175 | 2530 | 700 | 10150 | 300 | 11.81 | 1360 | 91 | OPB | MF+M00920-16 |
| EQ2-20 | 31 | -20 | 1-1/4″ | – | – | 47.0 | 1.85 | 150 | 2170 | 600 | 8700 | 420 | 16.54 | 2030 | 136 | OPB | MF+M00920-20 |
| EQ2-24 | 38 | -24 | 1-1/2″ | – | – | 53.4 | 2.10 | 100 | 1450 | 410 | 5940 | 500 | 19.69 | 2275 | 152 | OPB | MF+M00910-24 |
| EQ2-32 | 51 | -32 | 2″ | – | – | 66.2 | 2.61 | 90 | 1300 | 370 | 5360 | 630 | 24.80 | 3155 | 211 | OPB | MF+M00910-32 |
